FRP Tent Pole
Product Description Of FRP Tent Pole
The fiberglass tent pole is a tubular support material made by combining high-strength glass fiber filaments with epoxy resin through a high-temperature curing process. Its core structure consists of thousands of interlaced glass fiber filaments, each with a diameter of just 5-25 micrometers, forming a dense mesh reinforced by resin and coated with an anti-UV wear-resistant layer, achieving both lightweight and robust properties. Designed with a segmented modular system, each 30-60 cm section is connected by elastic Kevlar cords, enabling quick assembly, extension, or compact folding—reducing storage volume by 70% for easy transport in backpacks, car roof boxes, and other scenarios. The hollow structure, with an 8-12 mm diameter and 0.5-1.2 mm wall thickness, allows the tent pole (weighing only 300-500 grams for a 3-meter length) to withstand vertical pressures of 200-500N and endure extreme temperatures from -40°C to 80°C. Its matte finish minimizes glare in snowy or windy environments while resisting salt spray corrosion and UV degradation. Unlike traditional metal poles, its unique “memory rebound” feature enables 180° bending with instant recovery, a fatigue resistance of up to 100,000 bends without damage, and non-conductive properties that enhance safety during thunderstorms. These innovations make it a revolutionary choice for modern lightweight, high-performance tent frames.
| Parameter | Technical Specification/Description |
|---|---|
| Material Composition | Fiberglass (SiO₂ content ≥55%) + Epoxy Resin (thermosetting) |
| Fiber Density | 2.5g/cm³ (10% lighter than aluminum alloy) |
| Diameter Options | 8mm / 10mm / 12mm (Hollow tubular structure) |
| Wall Thickness Range | 0.5mm-1.2mm (Lightweight yet high-strength design) |
| Segment Length | 30cm / 45cm / 60cm (Modular assembly, connected by cords) |
| Flexural Strength | 200-500N (Vertical load capacity, equivalent to 20-50kg concentrated weight) |
| Tensile Strength | ≥800MPa (ISO 527 standard) |
| Bend Fatigue Resistance | >100,000 cycles (No structural damage in lab tests) |
| Operating Temperature | -40℃ ~ +80℃ (Stable in extreme conditions) |
| Corrosion Resistance | Passes -hour salt spray test (ASTM B117 standard) |
| UV Resistance | Reflects 90% UV radiation (Titanium dioxide coating) |
| Electrical Insulation | Non-conductive, eliminates lightning risks |
Application Of FRP Tent Pole
Applications: Versatility from Family Camping to Extreme Expeditions
Fiberglass tent poles adapt seamlessly to diverse outdoor scenarios.
1. Family and Leisure Camping
- Park Camping: Quick assembly of 3-6 person tents; child-friendly setup fosters education and fun.
- Roof-Top Tents: Lightweight design reduces vehicle load, compatible with SUVs and RVs.
- Picnic Shades: Multi-pole configurations create sun-blocking canopies with UV protection.
2. Professional Outdoor Adventures
- High-Altitude Mountaineering: Remains flexible at -30°C, supporting alpine tents in 10-level winds.
- Desert Expeditions: Sand-resistant coating minimizes abrasion, tolerating drastic temperature swings.
- **Water Sportsired with inflatable buoys, creates stable floating camping platforms.
3. Emergency Response and Military Use
- Disaster Relief Tents: Deployable in under 1 minute for rapid crisis response.
- Field Hospitals: Modular tent poles extend into medical shelter frames, bearing 200kg/m² loads.
- Temporary Facilities: Configure clotheslines, signal towers, or auxiliary equipment via joints.
4. Commercial and Public Infrastructure
- Outdoor Market Stalls: Wind-resistant pop-up booths for urban events.
- Open-Air Concerts: Discreet yet sturdy supports for lighting and sound systems.
- Eco-Monitoring Stations: Low-maintenance durabilitys, wetlands, and corrosive environments.
Advantages Of FRP Tent Pole
The rise of fiberglass tent poles is no coincidence—their comprehensive performance demonstrates significant competitiveness in the outdoor equipment industry.
1. Lightweight and Portability
- Glass fiber density (2.5g/cm³) is lower than aluminum alloy (2.7g/cm³), and its hollow structure further reduces weight.
- Folded volume shrinks by 70%, easily fitting into backpack side pockets, ideal for hiking, cycling, and long-distance sports.
2. Exceptional Flexibility and Fatigue Resistance
- Elongation at break reaches 3%-5%, far exceeding metals (0.5%-1.5%).
- Withstands over 100,000 bends without structural damage (lab-tested), perfect for windy or snowy environments.
3. All-Weather Durability
- Corrosion Resistance: Resin coating blocks moisture, passing 500-hour salt spray tests (ASTM B117) without rust.
- UV Resistance: Titanium dioxide-enhanced coating reflects 90% of UV rays, slowing material degradation.
- Insulation: Non-conductive properties eliminate lightning risks, outperforming metal tent poles in safety.
4. Cost-Effectiveness and Eco-Friendliness Costs 1/3 of carbon fiber tent poles, with low repair costs: single-section replacement avoids full pole disposal.
- Over 85% recyclability, compliant with EU RoHS environmental standards.
5. Noise Reduction and Comfort
- Low vibration frequency in strong winds reduces noise by 70% compared to metal tent poles, enhancing sleep quality.
- Surface temperature adapts to surroundings: no freezing in winter, no overheating in summer.
6. Safety Innovations
- Broken fibers disperse harmlessly as fuzz, avoiding sharp edges and cuts.
- High-end models integrate pressure sensors to trigger warning lights under extreme loads.
Customization Details
Customize The Diameter
- Common Specifications: The outer diameter generally ranges from a few millimeters to several tens of millimeters. Common ones include Φ6.0mm, Φ7.9mm, Φ8.5mm, Φ9.5mm, Φ11.0mm, Φ12.7mm, etc.
- Customization Range: Some manufacturers can customize diameters from 1mm to 130mm.
Customize the color
We can match any color based on standard color codes or provided samples.
Post-processing
We also offer various post-processing services for fiberglass rods, including sharpening, drilling, chamfering, rounding, slot cutting and more.
Packaging and shipping
To ensure the product reaches our customers intact, we will apply impact-resistant cushioning material around vulnerable areas of the base board, providing protection during transit.
